| 41360-000 | for CT | Quote |
|---|---|---|
| 41360-100 | for MECT | Quote |
The phantom facilitates study of image fusion between CT and ultrasound in combination with US-1 Echozy*. New variation for MECT has been added.
- abdomen
- multi energy
- dual energy
- echogy
- fusion study
PH-5
CT Abdomen Phantom
| Features | 1. Two variation to meet your requirements: CT type (no contrast enhancement) MECT type (vessels with 13mgI/ml** iodine and the liver of multi-energy CT compatible material). **Concentration of iodine can be custom-ordered. |
|---|---|
| Training skills / Applications | CT Multi energy CT |
| Set includes | 1 abdomen phantom / 1 set of sample X-ray data (DVD) / 1 storage case / manual |
| Size (approx.) | W27 x D16 x H30 cm W10.6 x D6.3 x H11.8 in |
| Packing size (approx.) | W44 x D39 x H42cm / W17.3 x D15.4 x H16.5in |
| Weight (approx.) | 12 kg / 26.4 lb |
| Packing weight (approx.) | 19kg / 42lb |
| Materials | Soft tissue: urethane based resin (density: 1.06) / Synthetic bone: epoxy resin (density: 1.31) |
| Anatomy | lungs (no internal structure) / heart (no internal structure) / liver / portal vein / gallbladder / hepatic vein / hepatic artery / kidneys / pancreas / spleen / aorta / IVC / spinal column / ribs / *Vessels and organs with a contrast agent can be included as a special order. |
| Update | July 20, 2020 |
